Description
MPPT Solar Charging Mode
- INVERTER MODEL: 3.6KW
- PV Array Power:6200W
- Nominal PV Voltage:360Vdc
- PV Array MPPT Voltage Range:90Vdc~450Vdc
- PV Array Open Circuit Voltage:500Vdc
- Max Charging Current (AC charger plus solar charger):120Amp
Grid-Tie Operation
- INVERTER MODEL:3.6KW
- Nominal Output Voltage:220/230/240 VAC
- Feed-in Grid Voltage Range:195~253VAC
- Feed-in Grid Frequency Range:49~ 51±1Hz
- Nominal Output Current:7A
- Power Factor Range:>0.99
- Maximum Conversion Efficiency (DC/AC):97%
Inverter Mode Specifications
- INVERTER MODEL: 3.6KW
- Rated Output Power: 3.6KW
- Output Voltage Waveform:Pure Sine Wave
- Output Voltage Regulation:230Vac±5%
- Output Frequency:50Hz
- Peak Efficiency:93%
- Nominal DC Input Voltage:24Vdc
To View Datasheet Press Here
