Description
| Specifications | Range | UT18B PRO | ||
| DC voltage (V) | 1000V | ±(0.5%+3) | ||
| AC voltage (V) | 1000V | ±(1%+3) | ||
| AC current (A) | 10A | ±(1%+3) | ||
| DC current (A) | 10A | ±(0.8%+3) | ||
| Resistance (Ω) | 60MΩ | ±(0.5%+2) | ||
| Capacitance (F) | 6000μF | ±(2%+5) | ||
| Frequency (Hz) | 10Hz~100kHz | |||
| 1MHz | ±(0.1%+3) | |||
| Duty cycle | 1%~99% | ±(1%+4) | ||
| Temperature (°C/℉) | -55℃~500℃/-67℉~932℉ | ±(2%+1) | ||
| Features | ||||
| Display count | 6000 | |||
| True RMS | √ | |||
| Auto range/Manual range | √ | |||
| LED test | 12V | √ | ||
| Continuity/Diode test | √ | |||
| Relative mode | √ | |||
| Data hold | √ | |||
| Max/Min | √ | |||
| Auto backlight | √ | |||
| Auto power off | Approximately 15 minutes | √ | ||
| Low battery indication | ＜2.5V approximately | √ | ||
| Drop test | 1m | √ | ||
| Overvoltage category | CAT III 1000V CAT IV 600V |
√ | ||
| General Characteristics | ||||
| Power | 1.5V battery (LR6) x 2 | |||
| Product net weight | 484g | |||
| Product size | 195mm x 95mm x 58mm | |||
| Standard accessories | English manual, test lead, temperature probe (UT17B PRO); temperature adapter socket(UT18B PRO), batteries | |||
| Standard individual packing | Gift box, cloth bag | |||
| Standard quantity per carton | 10pcs | |||
| Standard carton measurement | UT15B/17B PRO: 505mm x 355mm x 205mm; UT18B PRO： 480×370×195mmm |
|||
| Standard carton gross weight | UT15B PRO: 8.8kg; UT17B PRO: 9.1kg | |||
