Description
| Specification | Range | UT60EU | UT60BT | UT60S |
| DC Voltage | 9.999mV/99.99mV/999.9mV/ 9.999V/99.99V/999.9V |
±(0.5%+3) | ±(0.5%+3) | ±(0.5%+3) |
| AC Voltage | 9.999mV/99.99mV/999.9mV/ 9.999V/99.99V/999.9V |
±(0.8%+3) | ±(0.8%+3) | ±(0.8%+3) |
| DC Current | 999.9uA/999.9mA/9.999A/10A | ±(0.8%+3) | ±(0.8%+3) | ±(0.8%+3) |
| AC Current | 999.9uA/999.9mA/9.999A/10A | ±(1.0%+3) | ±(1.0%+3) | ±(1.0%+3) |
| Resistance | 999.9Ω/9.999kΩ/99.99kΩ/999.9kΩ/9.999MΩ/99.99MΩ | ±(0.8%+2) | ±(0.8%+2) | ±(0.8%+2) |
| Capacitor | 9.999nF/99.99nF/999.9nF/9.999μF/99.99μF/999.9μF/9.999mF/9.99mF (UT60EU/UT60BT)/99.9mF(UT60S) | ±(4.0%+5) | ±(4.0%+5) | ±(4.0%+5) |
| Frequency | 99.99Hz～9.999MHz | ±(0.1%+5) | ±(0.1%+5) | ±(0.1%+5) |
| Duty Cycle | 0.1～99.9% | ±(3%+5) | ±(3%+5) | ±(3%+5) |
| Temperatue | –40℃～1000℃/–40°F～1832°F | ±4℃/±5℉ | ±4℃/±5℉ | ±4℃/±5℉ |
| Features | ||||
| Bluetooth | yes | √ | ||
| Display Count | yes | 9999 | 9999 | 9999 |
| Auto Range | yes | √ | √ | √ |
| REL | yes | √ | √ | √ |
| NCV | yes | √ | √ | √ |
| Diode | yes | √ | √ | √ |
| Continuity Test | yes | √ | √ | √ |
| Acousto-optic Indication (NCV/continuity/battery power) | yes | √ | √ | √ |
| Low Battery Indication | ≤3.6V | √ | √ | √ |
| Data Hold | yes | √ | √ | √ |
| Auto Power Off | 15Min | √ | √ | √ |
| Operation Temperature | 0℃～40℃ | |||
| Safety | CAT II 1000V/CAT III 600V | |||
| General Characteristics | ||||
| Battery | 1.5V AAA x 3 | |||
| Product Color | Red and Gray | |||
| Product Net Weight | 290g | |||
| Product Size | 169mm x 81mm x 46mm | |||
| Standard Individual Packing | Gift Box, Manual, Thermocouple | |||
| Standard Quantity Per Carton | 20pcs | |||
| Standard Carton Size | 420mm x 320mm x 300mm | |||
