Description
Product features:
- Simple on-site processing
- Mating safety provided by keyed housings
- Multiple plugging and unplugging cycles
- High Voltage and Current carrying capacity
- Waterproof grade: IP67
- Housing made of PPO material, anti-UV
- CE approved
- Competitive price
Technical data:
- Name: MC4 T Branch Connector 3-1
- Rated current: 30A
- Rated voltage: 1000v DC
- Test voltage: 6000V(50Hz, 1min)
- Overvoltage type/pollution degree: CAT Ⅲ /2
- Contact resistance of plug connector: 1mΩ
- Contact material: Copper, Tin-plated
- Insulation material: PPO
- Degree of protection: IP67
- Safety class: Ⅱ
- Suitable cable: 2.5mm2, 4mm2, 6mm2
- Insertion force/withdrawal force: ≤50N/≥50N
- Connecting system: Crimp connection
